Hi Deepa,

kindly look at below url , this is the good example of mcv grid with paging

http://www.asp.net/mvc/overview/getting-started/getting-started-with-ef-using-mvc/sorting-filtering-and-paging-with-the-entity-framework-in-an-asp-net-mvc-application

Hope it will help you.

Regards,

Mehul Gajjar.

I need the steps for creating this grid in Umbraco.Is it need to create a webgrid in a partial view

Hi Deepa,

yes you need to create a webgrid in a partial view.

and if you need this in umbraco back office then you have to make a custom property editor.

Regards,

Mehul Gajjar.

This is my partial view

  @{
        UMMbr.Model.SOTI product = new UMMbr.Model.SOTI();
        var db = ApplicationContext.Current.DatabaseContext.Database;
        // Fetch a collection of contacts from the db.
        var listOfContacs = db.Fetch<UMMbr.Model.SOTI>(new Umbraco.Core.Persistence.Sql().Select("*").From("SOTI"));

    }

    @{
        var grid = new WebGrid(listOfContacs, canPage: true, rowsPerPage: 2, selectionFieldName: "selectedRow", ajaxUpdateContainerId: "gridContent");
        grid.Pager(WebGridPagerModes.NextPrevious);}
    <div id="gridContent">
        @grid.GetHtml(tableStyle: "webGrid",
                headerStyle: "header",
                alternatingRowStyle: "alt",
                selectedRowStyle: "select",
                columns: grid.Columns(
                                  grid.Column("Title", "Title"),
                                  grid.Column("Quarter", " Quarter"),
                                  grid.Column("Summary", "Summary", style: "description"),
                                           grid.Column("Link", "Link")
         ))
        @if (grid.HasSelection)
        {
            product = (UMMbr.Model.SOTI)grid.Rows[grid.SelectedIndex].Value;
            <b>Id</b> @product.Title<br />
            <b>Name</b>  @product.Quarter<br />
            <b>Description</b> @product.Summary<br />
            <b>Quantity</b> @product.Link<br />
        }

But paging is not working .

How can i get data from controller to webgrid?.

Hi Deepa,

For getting a data from controller you have to pass model to your partial view at the time of calling

you can access your model data after inherit using @import YOURNAME_SPACE.YOUR_MODEL in your partial view.

@model YOURNAME_SPACE.YOUR_MODEL
@using System.Web.Helpers;

Also see below example

https://our.umbraco.org/documentation/Reference/Mvc/partial-views

https://our.umbraco.org/documentation/Reference/Templating/Mvc/child-actions#RenderingaChildAction

You can pass parameters in your partial view like this:

Partial View Macro

@inherits Umbraco.Web.Macros.PartialViewMacroPage

@{
    Html.RenderPartial(
        "~/Views/Partials/YourPartial.cshtml",
        Model.Content,
        new ViewDataDictionary(this.ViewData) {
            { "FirstParam", "something" },
            { "SecondParam", true }
        }
    );
}

Partial View

@inherits Umbraco.Web.Mvc.UmbracoViewPage<IPublishedContent>

@{
var FirstParam= (string)ViewData["FirstParam"];
var SecondParam=  (bool)ViewData["SecondParam"];
}

This partial view is strongly typed and is passing the current page as the Model, so you can access properites like this:

Model.GetPropertyValue<string>("myprop")

Hope that's helpful

Regards

Mehul Gajjar.
