It still does not work, but I must be very close. Now I have three files:

App_Plugins/ImageWidthEditor/ImageWidthEditor.controller.js

angular.module("umbraco")
 .controller("My.ImageWidthEditorController",
 function () {
 });

App_Plugins/ImageWidthEditor/ImageWidthEditor.html

<div ng-controller="My.ImageWidthEditorController">
    <select ng-model="model.value" class="umb-editor umb-dropdown">
        <option value="20">20 %</option>
        <option value="30">30 %</option>
        <option value="40">40 %</option>
        <option value="50">50 %</option>
        <option value="100" selected>100 %</option>
    </select>
</div>

{
    parameterEditors: [
        {
            alias: "My.ImageWidthEditor",
            name: "Image Width Editor",
            editor: {
                view: "~/App_Plugins/ImageWidthEditor/ImageWidthEditor.html"
            }
        }
    ],
    javascript: [
        "~/App_Plugins/ImageWidthEditor/ImageWidthEditor.controller.js"
    ]
}

In the package.manifest put isParameterEditor: true

{
    propertyEditors:[
        {
            alias:"My.ImageWidthEditor",
            name:"Image Width Editor",

isParameterEditor: true,
            editor:{
                view:"~/App_Plugins/ImageWidthEditor/ImageWidthEditor.html"
            }
        }
    ],
    javascript:[
        "~/App_Plugins/ImageWidthEditor/ImageWidthEditor.controller.js"
    ]
}

Hello Arunabha!

Well, I am 120 percent sure that I tried that before but with no luck. After your suggestion I tried that again and now it works perfect, strange :)

Anyways, thank you very much!

Hi all,

For me just changing in package manifest doesn't work. I was creating a propertyeditor from c# and my code looks like in below:

    [PropertyEditor("mycontentpicker", "mycontentpicker", "/App_Plugins/mycontent/mycontentpicker.html", ValueType = "STRING", IsParameterEditor=true)]
    [PropertyEditorAsset(ClientDependencyType.Javascript, "/App_Plugins/mycontent/mycontentpicker.js")]
    public class MyContentPropertyEditor : PropertyEditor
    {
    }

Before

"IsParameterEditor=true"

was not there but was in package.manifest and doesnt' work. After changing the IsParameterEditor value into true in my class file it works.

Thanks
PTamang

Hi Pasang,

I already mentioned on my post, that In the package.manifest put isParameterEditor: true :)

@Petr i have been trying to duplicate what you have done, using same files and filenames etc but I dont seem to get "Image Width Editor" in the Macro Parameter / Type dropdown?

Does it need registred or something? Any advice greatfully received :)

Paul

Hi Paul,

Reset the iis and clear all browser cache Reload it. it will work.

Hi... when i try to fetch the value from the dropdown, i always get NULL.

var size = ViewData.Model.MacroParameters["size"];

What can be the case... my pluging is exactly the same

angular.module("umbraco").controller("TT.ImageSizeDropdown.ImageSizeController", function () {  });

<div ng-controller="TT.ImageSizeDropdown.ImageSizeController">
<select ng-model="model.value" class="umb-editor umb-dropdown">
    <option value="full">Heel</option>
    <option value="half">Half</option>
    <option value="quarter">Kwart</option>
</select>

{
propertyEditors: [
    {
        alias: "TT.ImageSizeDropdown",
        name: "Image Size",
        isParameterEditor: true,
        editor: {
            view: "~/App_Plugins/TT.ImageSizeDropdown/imagesizedropdown.html",
            valueType: "TEXT"
        }
    }
],
javascript: [
    "~/App_Plugins/TT.ImageSizeDropdown/imagesizedropdown.controller.js"
]}

I created a macro with Alias 'size' and Type the type above 'Image Size'.

Any help on why i get the NULL value when fetching it..

Hi Vishal,

Did you create the 'size' parameter on the macro itself in the Umbraco backend?

I am having a similar problem to Paul - I have replicated the code that Petr supplied, but I cannot see the ImageWidthEditor parameter in my list of macro parameters.

I have added the isParameterEditor: true to the package.manifest, reset IIS and cleared my cache but to no avail.

Does anyone have any ideas?

this has worked for me.

is there a documentation where these properties is listed out? I am a bit frustrated i have to keep searching in google.

Hi, bit late to the party but I have created a really simple custom dropdown plugin that you can download from github and read how to implement a custom umbraco dropdown parameter here
