    Umbraco Health: Database Schema Validation

    Hi,

    I've recently upgraded to 7.12.2 and now I've got the Health-checks. When I check my log for the Database Schema Validation messages, I see the following:

    Umbraco.Web.HealthCheck.Checks.DataIntegrity.DatabaseSchemaValidationHealthCheck - Some errors were detected while validating the database schema against the
    Umbraco.Web.HealthCheck.Checks.DataIntegrity.DatabaseSchemaValidationHealthCheck - Table: database_firewall_rules
    Umbraco.Web.HealthCheck.Checks.DataIntegrity.DatabaseSchemaValidationHealthCheck - Column: database_firewall_rules,id
    Umbraco.Web.HealthCheck.Checks.DataIntegrity.DatabaseSchemaValidationHealthCheck - Column: database_firewall_rules,name
    Umbraco.Web.HealthCheck.Checks.DataIntegrity.DatabaseSchemaValidationHealthCheck - Column: database_firewall_rules,start_ip_address
    Umbraco.Web.HealthCheck.Checks.DataIntegrity.DatabaseSchemaValidationHealthCheck - Column: database_firewall_rules,end_ip_address
    Umbraco.Web.HealthCheck.Checks.DataIntegrity.DatabaseSchemaValidationHealthCheck - Column: database_firewall_rules,create_date
    Umbraco.Web.HealthCheck.Checks.DataIntegrity.DatabaseSchemaValidationHealthCheck - Column: database_firewall_rules,modify_date
    Umbraco.Web.HealthCheck.Checks.DataIntegrity.DatabaseSchemaValidationHealthCheck - Index: IX_umbracoNode_uniqueID
    Umbraco.Web.HealthCheck.Checks.DataIntegrity.DatabaseSchemaValidationHealthCheck - Index: nci_wi_umbracoNode_F832BF0A5C74983020A6FFC23F949E30
    Umbraco.Web.HealthCheck.Checks.DataIntegrity.DatabaseSchemaValidationHealthCheck - Index: IX_umbracoNodeUniqueID
    Umbraco.Web.HealthCheck.Checks.DataIntegrity.DatabaseSchemaValidationHealthCheck - Constraint: FK_umbracoExternalLogin_umbracoUser_id
    Umbraco.Web.HealthCheck.Checks.DataIntegrity.DatabaseSchemaValidationHealthCheck - Constraint: FK_umbracoRedirectUrl
    Umbraco.Web.HealthCheck.Checks.DataIntegrity.DatabaseSchemaValidationHealthCheck - Constraint: FK_umbracoRedirectUrl_umbracoNode_uniqueID
    Umbraco.Web.HealthCheck.Checks.DataIntegrity.DatabaseSchemaValidationHealthCheck - Constraint: PK_umbracoMigrations
    Umbraco.Web.HealthCheck.Checks.DataIntegrity.DatabaseSchemaValidationHealthCheck - Constraint: PK_umbracoMigration


    How can I fix these issues? Can I find some SQL-statements to execute?

    Thanks!

  • Alex Skrypnyk 6163 posts 24143 karma points MVP 8x admin c-trib
    Sep 07, 2018 @ 08:54
    Alex Skrypnyk
    0

    Hi Jelle

    Do you know what "databasefirewallrules" table is? Did you create it ?

    Alex

  • Jelle 6 posts 46 karma points
    Sep 07, 2018 @ 09:52
    Jelle
    0

    Hi,

    No, I didn't create it. I've found this table as view under "Views > System Views" (in MS SQL Server Management Studio). My DB is a Azure SQL-DB.

  • Masahiko Isshiki 2 posts 22 karma points
    Sep 21, 2018 @ 09:36
    Masahiko Isshiki
    0

    I'm in the exactly same situation. I have two sites using Azure SQL-DB. And both sites has the same issues. So, I suspect it is a bug of "Umbraco Health: Database Schema Validation".

    One site is warning about "Table: database_firewall_rules". Another site is warning about "Table: database_firewall_rules", "Table: script_deployments" and "Table: script_deployment_status".

    These tables exists in system views of database like "sys.database_firewall_rules".

    I have no idea to fix this problem.

  • Dan Diplo 1554 posts 6205 karma points MVP 6x c-trib
    Sep 21, 2018 @ 12:42
    Dan Diplo
    0

    See this issue for more context: https://issues.umbraco.org/issue/U4-11580

  • Masahiko Isshiki 2 posts 22 karma points
    Oct 10, 2018 @ 06:50
    Masahiko Isshiki
    0

    According to the following issue page, this problem seems to be avoidable in the next version 7.13.0.
    "Disable DatabaseSchemaValidationHealthCheck until we can make it give proper recommendations · Issue #3132 · umbraco/Umbraco-CMS"


    I think ValidateDbTables() method in DatabaseSchemaCreation.cs file of the version 7.12.3 shoud be fixed.

    foreach (var tableName in invalidTableDifferences)
    {
      // TODO: I think this code is adding all tables that differ between the umbraco tables and the real tables.
      // But this code should ignore unknown tables that are not included in the umbraco defined tables.
      result.Errors.Add(new Tuple<string, string>("Table", tableName));
    }


    I think that it's better to check this thought to fix the problem, but I have no enough time to check now...
